Container Specification
 Door Opening Internal Dimensions
Standard
  Cubic Capacity Max.Payload
TYPE CBFT CBM LBS KGS
20' x 8'6" 1,140.7 32.3 47,711 21,687
40' x 8'6" 2,362.5 66.9 58,036 26,380
40' x 9'6" 2,705.1 76.6 57,288 26,040
Standard
Width Height Lenth Width Height
IN MM IN MM IN MM IN MM IN MM
90.7 2,305 89.6 2,276 233.0 5,918 91.7 2,330 92.8 2,356
91.7 2,330 89.7 2,278 473.0 12,015 91.7 2,330 94.1 2,389
92.1 2,339 102.0 2,591 473.7 12,033 92.5 2,350 106.1 2,700

Reefers
  Cubic Capacity Max.Payload
TYPE CBFT CBM LBS KGS
20' Insulated 928.8 26.3 39,934 18,152
20' Integral 985.5 28.0 44,968 20,440
Reefers
Width Height Lenth Width Height
IN MM IN MM IN MM IN MM IN MM
87.9 2,235 81.5 2,077 223.5 5,677 88.0 2,236 81.8 2,077
89.4 2,270 87.5 2,222 215.7 5,480 88.5 2,248 88.5 2,247

Specialised
  Cubic Capacity Max.Payload
TYPE CBFT CBM LBS KGS
20' Open Top 1,140.7 32.3 39,908 18,140
40' Open Top 2,355.5 66.7 58,366 26,530
20' Flat Rack 1,147.7 32.5 46,420 21,100
40' Flat Rack 2,295.4 65.0 57,816 26,280
Specialised
Width Height Lenth Width Height
IN MM IN MM IN MM IN MM IN MM
91.3 2,318 89.5 2,273 231.7 5,885 91.3 2,319 93.1 2,366
91.9 2,335 90.0 2,287 473.1 12,017 91.8 2,333 91.3 2,318
- - - - 232.3 5,900 94.4 2,397 90.7 2,303
- - - - 473.8 12,035 91.9 2,335 91.1 v2,315
